Stacking

Introduction

Gum supports creating vertical and horizontal stacks of children. Stacked children can also be wrapped and support spacing between each item.

This document provides a deep dive into Gum stacking behavior, which is the default behavior for StackPanel, ItemsControl, and ListBox.

Using StackPanel for Stacking

The StackPanel provides stacking behavior for its children. The following code shows how to add stacked Buttons to a StackPanel:

// Initialize
var stackPanel = new StackPanel();
stackPanel.AddToRoot();
stackPanel.Anchor(Gum.Wireframe.Anchor.Center);

for(int i = 0; i < 10; i++)
{
    var button = new Button();
    stackPanel.AddChild(button);
    button.Text = $"Button {i}";
}

StackPanel exposes some of the stack-related properties; however, we will be accessing its Visual to have full control over stacking for the remainder of this documentation.

Adding Spacing with StackSpacing

The StackSpacing variable can be used to add spacing between each stacked item, as shown in the following code:

// Initialize
var stackPanel = new StackPanel();
stackPanel.AddToRoot();
stackPanel.Anchor(Gum.Wireframe.Anchor.Center);

var stackPanelVisual = stackPanel.Visual;
stackPanelVisual.StackSpacing = 4;

for(int i = 0; i < 10; i++)
{
    var button = new Button();
    stackPanel.AddChild(button);
    button.Text = $"Button {i}";
}

Buttons with spacing

Horizontal Stacking

We can change the stacking direction by changing the ChildrenLayout property as shown in the following code. Note that the Buttons have been made narrower so they all fit on screen.

// Initialize
var stackPanel = new StackPanel();
stackPanel.AddToRoot();
stackPanel.Anchor(Gum.Wireframe.Anchor.Center);

var stackPanelVisual = stackPanel.Visual;
stackPanelVisual.ChildrenLayout =
    Gum.Managers.ChildrenLayout.LeftToRightStack;

for(int i = 0; i < 10; i++)
{
    var button = new Button();
    button.Width = 60;
    stackPanel.AddChild(button);
    button.Text = $"Button {i}";
}

Buttons stacking horizontally

Wrapping

Stacked children can also be wrapped horizontally. Before wrapping can happen, the parent StackPanel must not depend on its children's size in its primary stacking direction. For example, if a StackPanel is using its default vertical stacking, then its Height must not depend on its children - otherwise it stretches indefinitely to contain its children.

The following code shows how to set an absolute Height on the parent StackPanel and enable wrapping:

// Initialize
var stackPanel = new StackPanel();
stackPanel.AddToRoot();
stackPanel.Anchor(Gum.Wireframe.Anchor.Center);
stackPanel.HeightUnits = Gum.DataTypes.DimensionUnitType.Absolute;
stackPanel.Height = 150;

var stackPanelVisual = stackPanel.Visual;

stackPanelVisual.WrapsChildren = true;

for(int i = 0; i < 10; i++)
{
    var button = new Button();
    stackPanel.AddChild(button);
    button.Text = $"Button {i}";
}

Children stacked vertically and wrapped

Notice that since the StackPanel has had Anchor(Anchor.Center) called, it remains centered as it wraps and expands horizontally.

Bottom-Up and Right-to-Left Stacking

A StackPanel's Visual only provides two possible stacking modes:

• ChildrenLayout.TopToBottomStack (default)
• ChildrenLayout.LeftToRightStack

There is no dedicated "bottom-up" or "right-to-left" mode, but you can create either by combining Anchor (or Dock) with ChildrenLayout. In both cases the StackPanel is anchored to one edge, so it stays pinned to that edge and grows in the opposite direction as children are added.

Bottom-Up Stacking

The following code creates a bottom-up stack similar to a chat room or command line. The StackPanel is anchored to the bottom, so newly-added children appear at the bottom and older children are pushed up:

// Class scope
StackPanel stackPanel;

protected override void Initialize()
{
    GumUI.Initialize(this);

    stackPanel = new StackPanel();
    stackPanel.AddToRoot();
    stackPanel.Anchor(Gum.Wireframe.Anchor.Bottom);

    base.Initialize();
}

protected override void Update(GameTime gameTime)
{
    GumUI.Update(gameTime);

    if(GumUI.Keyboard.KeyPushed(Microsoft.Xna.Framework.Input.Keys.Enter))
    {
        var label = new Label();
        stackPanel.AddChild(label);
        int index = stackPanel.Children.Count;
        label.Text = $"{index}: Added at {System.DateTime.Now}";
    }

    base.Update(gameTime);
}

Bottom-up stack

Right-to-Left Stacking

Right-to-left stacking uses the same approach horizontally: set ChildrenLayout to LeftToRightStack and anchor the StackPanel to the right. The stack stays pinned to the right edge and grows toward the left as children are added, so the newest item appears on the right:

// Class scope
StackPanel stackPanel;

protected override void Initialize()
{
    GumUI.Initialize(this);

    stackPanel = new StackPanel();
    stackPanel.AddToRoot();
    stackPanel.Anchor(Gum.Wireframe.Anchor.Right);
    stackPanel.Visual.ChildrenLayout =
        Gum.Managers.ChildrenLayout.LeftToRightStack;

    base.Initialize();
}

protected override void Update(GameTime gameTime)
{
    GumUI.Update(gameTime);

    if(GumUI.Keyboard.KeyPushed(Microsoft.Xna.Framework.Input.Keys.Enter))
    {
        var label = new Label();
        stackPanel.AddChild(label);
        int index = stackPanel.Children.Count;
        label.Text = $"Item {index}";
    }

    base.Update(gameTime);
}

TODO: Add a gif showing right-to-left stacking (newest item appearing on the right, older items pushed to the left).

Evenly-Sized Stacked Children

Stacking can be combined with ratio sizes to create evenly-sized children.

If children use a Height Units of Ratio, then they are sized according to the size of their parent and the size of their siblings. Since children depend on the parent's size, the parent should not depend on its children for its height.

The following code creates buttons which all share the height of their parent StackPanel.

// Class scope
StackPanel stackPanel;

protected override void Initialize()
{
    GumUI.Initialize(this);

    stackPanel = new StackPanel();
    stackPanel.AddToRoot();
    stackPanel.Anchor(Gum.Wireframe.Anchor.Center);
    stackPanel.HeightUnits = Gum.DataTypes.DimensionUnitType.Absolute;
    stackPanel.Height = 200;

    base.Initialize();
}

protected override void Update(GameTime gameTime)
{
    GumUI.Update(gameTime);
    if(GumUI.Keyboard.KeyPushed(Microsoft.Xna.Framework.Input.Keys.Enter))
    {
        var button = new Button();
        stackPanel.AddChild(button);
        button.HeightUnits = Gum.DataTypes.DimensionUnitType.Ratio;
        button.Height = 1;
        button.Text = $"Button {stackPanel.Children.Count}";
    }
    base.Update(gameTime);
}

Children Buttons stacked with Ratio size
