  1. Gum Tool

Setup

PreviousIntroductionNextRunning from Source

Last updated 13 days ago

Was this helpful?

Gum Application (binaries):

  • Latest release direct link:

  • Release history (including older releases):

Gum Source Code:

Windows

Currently the Gum tool requires XNA runtimes. Download and install the runtime prior to running Gum:

The current preview build of Gum no longer requires XNA. You can use this preview version instead of installing XNA. See the latest releases page for more info:

Since Gum is a prebuilt file in a .zip, Windows blocks the file which results in the "Windows protected your PC" popup:

You can click More info, then Run anyway. Alternatively, you can right-click on the .zip file and select the option to unblock:

MacOS

Prerequisites

Before proceeding, ensure that you have the following prerequisites installed on your system:

  1. Homebrew

  2. WINE

  3. Winetricks

Install Homebrew

Install WINE and Winetricks

You can install WINE and Winetricks using Homebrew. Open a terminal and run the following commands:

brew install --cask --no-quarantine wine-stable
brew install winetricks

Automated Setup MacOS

The following goes through the steps do download and run the setup_gum_mac.sh automation script. This script goes through the steps for you with minimal interaction to setup your environment on macOS to run the GUM tool using WINE. If you would prefer to do this setup manually, please see the Manual Setup Steps section below.

  1. Open a terminal and cd to the directory that the script was downloaded to

  2. Make the script executable

chmod +x ./setup_gum_mac.sh
  1. Execute the script

./setup_gum.mac.sh

Linux

Prerequisites

You will need these following prerequisites installed on your system, you can run the automated install script to have them installed automatically or you can install them yourself manually if you run into issues (see Manual Setup Steps section):

  1. WINE

  2. Winetricks

Automated Setup Linux

These following commands will go through the steps of downloading and running the setup_gum_linux.sh script. This script goes through the steps for you with minimal interaction required to setup your Linux environment to run the GUM tool using WINE. If you would prefer to do this setup manually, please refer to the Manual Setup Steps section below.

  1. Open a terminal and cd to the directory that the script was downloaded to

  2. Make the script executable

chmod +x ./setup_gum_linux.sh
  1. Execute the script

./setup_gum_linux.sh

Install WINE and Winetricks Manually

If the auto script fails to install the prerequisites try this.

You can install WINE and Winetricks using your package manager. Open a terminal and run the following commands:

If your distro is not listed bellow please use your prefered search engine to find out how to install wine and winetricks properly on your system.

Ubuntu 22.04

sudo dpkg --add-architecture i386
sudo mkdir -pm755 /etc/apt/keyrings
wget -O - https://dl.winehq.org/wine-builds/winehq.key | sudo gpg --dearmor -o /etc/apt/keyrings/winehq-archive.key -
sudo wget -NP /etc/apt/sources.list.d/ https://dl.winehq.org/wine-builds/ubuntu/dists/jammy/winehq-jammy.sources
sudo apt update && sudo apt install --install-recommends winehq-stable
sudo apt-get -y install winetricks

Ubuntu 24.04

sudo dpkg --add-architecture i386
sudo mkdir -pm755 /etc/apt/keyrings
wget -O - https://dl.winehq.org/wine-builds/winehq.key | sudo gpg --dearmor -o /etc/apt/keyrings/winehq-archive.key -
sudo wget -NP /etc/apt/sources.list.d/ https://dl.winehq.org/wine-builds/ubuntu/dists/noble/winehq-noble.sources
sudo apt update && sudo apt install --install-recommends winehq-stable
sudo apt-get -y install winetricks

Fedora & Nobara (All Versions)

sudo dnf install wine
sudo dnf install winetricks

Linux Mint 20

sudo apt install dirmngr ca-certificates software-properties-common apt-transport-https curl -y
sudo dpkg --add-architecture i386
curl -s https://dl.winehq.org/wine-builds/winehq.key | sudo gpg --dearmor | sudo tee /usr/share/keyrings/winehq.gpg > /dev/null
echo deb [signed-by=/usr/share/keyrings/winehq.gpg] http://dl.winehq.org/wine-builds/ubuntu/ focal main | sudo tee /etc/apt/sources.list.d/winehq.list
sudo apt-get install winetricks

Linux Mint 21

sudo apt install dirmngr ca-certificates software-properties-common apt-transport-https curl -y
sudo dpkg --add-architecture i386
curl -s https://dl.winehq.org/wine-builds/winehq.key | sudo gpg --dearmor | sudo tee /usr/share/keyrings/winehq.gpg > /dev/null
echo deb [signed-by=/usr/share/keyrings/winehq.gpg] http://dl.winehq.org/wine-builds/ubuntu/ jammy main | sudo tee /etc/apt/sources.list.d/winehq.list
sudo apt-get install winetricks

Linux Mint 22

sudo apt install dirmngr ca-certificates software-properties-common apt-transport-https curl -y
sudo dpkg --add-architecture i386
curl -s https://dl.winehq.org/wine-builds/winehq.key | sudo gpg --dearmor | sudo tee /usr/share/keyrings/winehq.gpg > /dev/null
echo deb [signed-by=/usr/share/keyrings/winehq.gpg] http://dl.winehq.org/wine-builds/ubuntu/ noble main | sudo tee /etc/apt/sources.list.d/winehq.list
sudo apt-get install winetricks

Manual Setup Steps

These following commands will go through the steps setting up your macOS or Linux environment to run the GUM tool using WINE.

  1. Open a new terminal

  2. Install .NET Framework 4.8 using winetricks with the following command:

winetricks dotnet48

This command initiates the installation of .NET Framework 4.8. A total of two installer dialogs appear one after another. Follow the steps for both to complete the installation. This process may take a several minutes, so please be patient.

  1. Download the XNA 4.0 Redistributable MSI file from Microsoft. You can download it using the following command:

curl -O https://download.microsoft.com/download/A/C/2/AC2C903B-E6E8-42C2-9FD7-BEBAC362A930/xnafx40_redist.msi
  1. After downloading the MSI file, install it using the following command:

wine msiexec /i xnafx40_redist.msi

Follow the installation prompts. At the end of the installation, it may display an error related to launching DirectX. This is normal; just click "Close" on the error dialog.

  1. Download the Gum Tool ZIP file from the FlatRedBall website and save it to your preferred location. You can download it using the following command:

curl -o Gum.zip https://files.flatredball.com/content/Tools/Gum/Gum.zip
  1. Unzip the downloaded Gum Tool ZIP file into the Program Files directory of the WINE folder. Run the following command in the terminal:

unzip Gum.zip -d ~/.wine/drive_c/Program\ Files/Gum
  1. After unzipping the Gum Tool, remove the downloaded ZIP file using the following command:

rm -f Gum.zip
  1. Create a script to run the Gum Tool. Run the following command in the terminal:

echo '#!/bin/bash
wine ~/.wine/drive_c/Program\\ Files/Gum/Data/Gum.exe' > ~/bin/Gum
  1. Make the script executable by running:

chmod +x ~/bin/gum
  1. To ensure you can run the Gum Tool from any directory, add the script directory to your PATH. Most Linux and macOS users using macOS 10.14 or lower, will be using the BASH shell. While for most macOS user using macOS 10.15 or higher, you'll be using the ZSH shell.

For Bash SHELL

if ! grep -q 'export PATH="\$HOME/bin:\$PATH"' ~/.bash_profile 2>/dev/null; then
    echo 'export PATH="$HOME/bin:$PATH"' >> ~/.bash_profile
fi

For ZSH Shell

if ! grep -q 'export PATH="\$HOME/bin:\$PATH"' ~/.zshrc 2>/dev/null; then
    echo 'export PATH="$HOME/bin:$PATH"' >> ~/.zshrc
fi
  1. Reload the shell configuration to apply the changes. Run the following command:

For BASH Shell

source ~/.bash_profile

For ZSH Shell

source ~/.zshrc

Running the Gum Tool

Congratulations! You have now successfully set up the Gum Tool on macOS using WINE. You can open the Gum Tool by simply typing the following command in the terminal:

gum

If the command doesn't work immediately, try closing and reopening the terminal.

Homebrew is a package manager for macOS. If you haven't installed Homebrew yet, you can install it by following the instructions on the .

Download the setup_gum.mac.sh script

Download the setup_gum.linux.sh script
